Rotary Screw Single Stage Gasoline - AR1-PK37-M

Limited Warranties:
  • 3 Year Kohler Engine
  • 3 Year Standard when Rotorlub Oil, Filter, and Parts are used

Download Catalog »


Powered by industry proven components, the patented Mi-T-M Rotary Screw Compressor works great in a wide variety of applications. This compact machine produces 115 CFM @ 100 PSI, and the 10-1/2-gallon fuel tank gives you the extended run time needed on many jobsites.

Compressor Pump:  Integrated air/oil separator · Integrated thermostatic bypass valve · Integrated oil filter · Banded 4 V-belt drive system · Easy-to-read oil level indicator · High oil temperature shutdown

Engine:  Electric start - battery and cables included · Low-oil level shutdown

Frame:  Powder coated steel frame with 1-1/4-inch roll cage, handle, 4-point lifting hook, winch point and tie-down anchors · 15-inch pneumatic tires

Components:  10-1/2-gallon aluminized steel fuel tank · Oil cooler with guard · Pressure gauge · Ball valve controlled 3/4-inch outlet · Adjustable pilot valve adjusts engine RPM based on air power needed

View Product Sheet »

Find a Dealer »


  • CFM @ PSI

    115 @ 100

  • Displacement/ Engine

    999cc Kohler CH1000 OHV

  • Compressor

    Single stage, rotary screw

  • Engine Idle Control


Weights & Dimensions

  • Net Weight

    698 lbs.

  • Shipping Weight

    770 lbs.

  • Length

    50.75 in.

  • Width

    30.5 in.

  • Height

    43.5 in.


  • AX-0076

    Skid feet
